| Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| IP Camera Input | Up to 6 channels of IPC access 2 IP channels by default + 4 channels (analog channels are converted to IP channels) incoming bandwidth: 32 Mbps, recording bandwidth: 32 Mbps and outgoing bandwidth: 32 Mbps *After IP channels are added beyond the existing channels, the AI Function (SMD) will be disabled |
| Two-way Talk | Support (share the same audio input with the first channel) |
| User Interface | Web; Local GUI |
| Video Output | 1 HDMI, 1 VGA HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Video Recording | Mainstream: All channel 5M-N (1 fps–12 fps); 4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/ D1/CIF (1 fps–25/30 fps) Sub stream: D1/CIF (1 fps–15 fps) |
| Resolution | 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF |
| Camera Input | 1. CVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps. 2. TVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 3. AHD: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 4. CVBS: PAL/NTSC |
| Video Compression | H.265/H.264+/H.264 |
| Video Display Split | 1/4 |
| Encode Strategy | AI Instream; Interstream |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Output | 1 channel, RCA |
| Audio Input | 1-channel RCA 4-channel BNC (Coaxial Audio) |
| Audio Sample Rate | 8KHz, 16 bit Per Channel |
| Network Mode | Single-address mode |
| Bit Rate | 32 kbps–6144 kbps per channel |
| Smart Phone | iPhone, iPad, Android Phone |
| General Alarm | Motion detection, video loss, tampering |
| Audio Bit Rate | 32Kbps Per Channel |
| Hard Disk | 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature |
| Anomaly Alarm | No disk, disk error, low space, offline, Ip conflict, MAC conflict |
| Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset |
| Recording Mode | General, motion detection, alarm, POS |
| Recording Playback | 1/4 Ch. |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second) |
| Backup Mode | USB Device and Network |
| Playback | Instant playback, general playback, event playback, tag playback |
| Ethernet | 1 Port (10/100 Mbps Ethernet port, RJ-45) |
| Interface Ports | 2 USB Ports (USB 2.0) |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DNS; P2P; ONVIF 21.06; CGI Conformant |
| Power Supply | DC12V/2A |
| Power Consumption | <4W (without HDD) |
| Operating Temperature | -10 °C to +50°C (+14 °F to +131 °F) |
| Operating Humidity | 0%–90% (RH) |
| Dimension | 197.0mm × 203.4 mm × 415 mm (7.76'' × 8.01'' × 1.63'') (W × D × H) |
| Weight | 0.55kg |
| Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| IP Camera Input | Up to 6 channels of IPC access 2 IP channels by default + 4 channels (analog channels are converted to IP channels) incoming bandwidth: 32 Mbps, recording bandwidth: 32 Mbps and outgoing bandwidth: 32 Mbps *After IP channels are added beyond the existing channels, the AI Function (SMD) will be disabled |
| Two-way Talk | Support (share the same audio input with the first channel) |
| User Interface | Web; Local GUI |
| Video Output | 1 HDMI, 1 VGA HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Video Recording | Mainstream: All channel 5M-N (1 fps–12 fps); 4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/ D1/CIF (1 fps–25/30 fps) Sub stream: D1/CIF (1 fps–15 fps) |
| Resolution | 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF |
| Camera Input | 1. CVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps. 2. TVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 3. AHD: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 4. CVBS: PAL/NTSC |
| Video Compression | H.265/H.264+/H.264 |
| Video Display Split | 1/4 |
| Encode Strategy | AI Instream; Interstream |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Output | 1 channel, RCA |
| Audio Input | 1-channel RCA 4-channel BNC (Coaxial Audio) |
| Audio Sample Rate | 8KHz, 16 bit Per Channel |
| Network Mode | Single-address mode |
| Bit Rate | 32 kbps–6144 kbps per channel |
| Smart Phone | iPhone, iPad, Android Phone |
| General Alarm | Motion detection, video loss, tampering |
| Audio Bit Rate | 32Kbps Per Channel |
| Hard Disk | 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature |
| Anomaly Alarm | No disk, disk error, low space, offline, Ip conflict, MAC conflict |
| Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset |
| Recording Mode | General, motion detection, alarm, POS |
| Recording Playback | 1/4 Ch. |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second) |
| Backup Mode | USB Device and Network |
| Playback | Instant playback, general playback, event playback, tag playback |
| Ethernet | 1 Port (10/100 Mbps Ethernet port, RJ-45) |
| Interface Ports | 2 USB Ports (USB 2.0) |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DNS; P2P; ONVIF 21.06; CGI Conformant |
| Power Supply | DC12V/2A |
| Power Consumption | <4W (without HDD) |
| Operating Temperature | -10 °C to +50°C (+14 °F to +131 °F) |
| Operating Humidity | 0%–90% (RH) |
| Dimension | 197.0mm × 203.4 mm × 415 mm (7.76'' × 8.01'' × 1.63'') (W × D × H) |
| Weight | 0.55kg |
We are the No. 1 distribution house in Bihar, Jharkhand, and Nepal, specializing in state-of-the-art CCTV and surveillance solutions. Available on the GeM portal, we have successfully completed numerous government projects. For further inquiries, please email us at info@uniworldvision.com or call us at 0806 9160 400.
